MT-SG2912F

Industrial Ethernet Ring with Zero Delay and Zero Packet Loss

• MT-SG2912F supports industrial Ethernet ring network protection protocol. The protection switching time is less than 50ms. The solution has been applied in power industry, rail transportation industry and military projects for decades. It can achieve zero

Carrier-class Ethernet Switches

• The MT-SG2912F supports carrier Ethernet ring network protection protocol. The protection switching time is less than 50ms. It also supports simple and effective redundancy protection mechanism such as STP/RSTP/MSTP protocol and dual uplink standby link protection and LACP link aggregation. These functions meet the requirement of carrier grade high reliability.
• The solution has perfect Ethernet OAM, which can real time monitor the network operating state and rapidly detect and locate the malfunction.
• The solution supports strong ACL function. The solution supports L2~L7 data access and control based on the physical port, VLAN IDs, source MAC/IP addresses and protocol port, which provides flexible ways of policy control.
• The MT-SG2912F supports ISSU (In-Service Software Upgrade), guaranteeing the user data non-stop forwarding when the system is upgrading.
• The MT-SG2912F supports various L2 multicast function, including IGMP-Snooping, user fastleave mechanism and cross VLAN multicast replication function

Carrier QoS Policies

• The MT-SG2912F supports complex traffic classification based on VLAN, source MAC/IP addresses, destination MAC/IP addresses, IP protocols, or priorities. It also supports priority remark. These functions provide an effective way for users to optimize their businesses.
• The MT-SG2912F provides flexible bandwidth control policies and support a port base or flowbased Committed Access Rate (CAR) and guarantees Layer 3 line-speed forwarding.
• Every port supports 8 priority queues.
• The MT-SG2912F also supports multiple queue grooming algorithms such as SP, WRR or SP+WRR.

Comprehensive IPv6 Solutions

• The MT-SG2912F comprehensively supports IPv6 Neighbor Discovery, ICMPv6 、Path MTU Discovery.
• The MT-SG2912F supports IPv6 based Ping, Traceroute, Telnet, SSH, ACL, meeting the need of IPv6 network equipment management and service control.

Comprehensive Security Mechanisms

• The MT-SG2912F adopts advanced hardware architecture design, realizing the hierarchical scheduling and protection of the packet. It provides multiple security measures to defend against DOS or TCP attacks; and supports command line authority control based on user levels.
• Comprehensive Security Certification: The MT-SG2912F complies with IEEE 802.1x, Radius, TACACS+.
• The MT-SG2912F supports the suppression of broadcast, multicast and unknown unicast packet, ensuring the equipment can operate normally in harsh network conditions.
• The MT-SG2912F has the perfect loop detection mechanism.
• The MT-SG2912F supports the port isolation in a same VLAN and DHCP-Snooping、IP+MAC+ port binding.

Convenient Management and Maintenance

• The MT-SG2912F supports multiple management styles such as Console, Telnet, SSH.
• The MT-SG2912F supports WEB based management. The management is simpler and more effective.
• The MT-SG2912F supports upload and download of TFTP files.
• The MT-SG2912F supports ISSU (In-Service Software Upgrade).
• The MT-SG2912F supports SNMP. By cooperating with Baud's smart "NMS”, functions including the equipment auto-discovery, the topology management, the equipment configuration management, the performance data analysis, and the fault management can be realized. In this way, the network management is simplified and the user gets a new product experience.
• The MT-SG2912F series is compatible with mainstream third-party optical modules.
