MT-24 CORE

Description

1.1 SCOPE

This specification covers the design requirements and performance standard for the supply of optical fiber cable. This specification covers the general requirements and performance of cable which our offering including optical characteristics, mechanical characteristics and geometrical characteristics.

1.2 CABLE DESCRIPTION

Loose tube cable is a design that has high tensile strength and flexibility in a compact cable size. Our loose tube cable provides excellent optical transmission and physical performance.

1.3 QUALITY

We ensures a continuing level of quality in our cable products through several quality control programs including ISO 9001 and all the materials have passed REACH and ROHS.

1.4 RELIABILITY

We ensure product reliability through rigorous qualification testing of each product family. Both initial and periodic qualification testing are performed to assure the cable’s performance and durability in the field environments.

1.5 REFERENCE
The cable which Our offering are designed, manufactured and tested according to international standards as follows:

IEC 60794-1-1

Optical fiber cables. Part 1: Generic specification

IEC 60794-1-2

Generic specification- basic optical cable test procedures

IEC 60793-3

Outer cables- sectional specification

IEC 60794-3-20

Outdoor cables- family specification for optical self-supporting aerial telecommunication cables

EIA/TIA 598 B

Color code of fiber optic cables

ITU-T G.650

Definition and test methods for the relevant parameters of single-mode fibers

ITU-T G.652

Characteristics of a single-mode optical fiber cable

ITU-T G.655

Characteristics of a non-zero dispersion-shifted single-mode optical fiber and cable

2. OPTICAL FIBER
The optical fiber is made of high pure silica and germanium doped silica. UV curable acrylate material is applied over fiber cladding as optical fiber primary protective coating. The detail data of optical fiber performance are shown in the following table.

OFS G.652 fiber use special spun device successfully controlled the value of PMD, and make sure that it keeps stable in cabling.

Approved by optical communication products ministry of quality supervision and inspection center, the connection between OFS fiber in and outside is good .The single-end connect-loss won’t be over 0.1dB and the double-end connect-loss is all little than 0.05dB.
Apply to non-relay communication network. Features: proof test >1%

OPTICAL FIBER CHARACTERISTICS (G.652 FIBER)

Category

Description

Specifications

Before cabling

After cabling

Optical Specifications

Attenuation @1550 nm

≤0.20 dB/km (max.)

≤0.22 dB/km (max.)

Attenuation @1625 nm

≤0.23dB/km

≤ 0.24 dB/km

Zero Dispersion Wavelength

≤1520 nm

Zero Dispersion Slope

≤ 0.084 ps/nm2·km

Polarization Mode Dispersion(PMD)

≤0.08 ps/km

Cable Cutoff Wavelength (λcc)

≤1450 nm

Macro bending Loss

(1 turn; Ф32 mm) @1550 nm

(100 turns; Ф60 mm) @1625 nm

(100 turns; Ф50 mm) @1310 &@1625 nm

≤ 0.05 dB ≤ 0.05 dB

≤0.05 dB

Mode Field Diameter

@1550 nm

9.6±0.5μm

DimensionSpecifications

Cladding Diameter

124.8 ±0.7μm

Core/clad concentricity error

≤0.6μm

Cladding Non-Circularity

≤1.0%

Mechanical Specifications

Min bending radius

12.5D (static)

25D (dynamic)

Proof Test level

≥1.2%

Fiber Curl Radius

≥4.0m

Peak Coating Strip Force

0.9~6.8N

CABLE STRUCTURE

3.1.1 DIMENSION AND PROPERTIES

General properties

Unit

Value

Fiber count (G.652)



2-24

Max. No of loose tube



1

Fiber No. per tube



MAX 24

Loose tube

mm

2.0-2.5

Steel wire

pc

2

Armor

material

Corrugated steel tape

Water blocking tape thickness

mm

0.2

Outer sheath material

mm

MDPE

Cable OD

mm

9 ±0.3

Cable weight

Kg/km



Max. allowable pulling force

N

1500/600

Crush resistance

N/100mm

1000/300

Remark: The weight of zinc coating of steel wire surface shall be no less than 20 g/m2. Strand shall have a left lay.

3.1.2 WORKING CONDITIONS



Temperature range

Transport and storage:- 4℃ to +70℃

Min Bending Radius

Installation:-10℃ to +60℃

Installation: 20 x OD

Operation:-40℃ to +70℃

Operation: 10 x OD

Note: 1. the nominal outer diameter may vary by ± 5%. 2. The nominal cable weight may vary by ±10%.

Categories: ,

Overview

MT-12 Core Fiber is an outdoor use optical fiber cable suitable for duct and aerial applications. Fiber optic cable GYXTW, 4 fibers, jelly filled and fiber contained central loose tube, copolymer coated steel tape, two parallel steel wires 0.8mm, PE outer sheath 7.5mm, G652D SM fiber.

Outdoor Fiber Optic Cable GYXTW Applications:
Laying modes: Aerial & Conduit
Rural communication, local trunk line, CATV & computer networks system.

Features

  • Low dispersion and attenuation.
  • Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties.
  • Double-jacket structure make cable have nice properties of moisture resistance and crush resistance with small cable diameter, light cable weight, easily to lay.
  • Compact structure, light weight, steel tape armored excellent water-proof layer, good moisture.
  • Operating Temperature: -40 ~ +60 ℃.
