MT-212GS 10/100Mbps WDM Single-Mode Media Converter

  • 1× SC/UPC Port
  • 1× RJ45 Port
  • Up to 20 km
  • Wavelength 1550nm

WDM Fast Ethernet Media Converter

Description

The MT-211GS is a media converter designed to convert 100BASE-LX/LH fiber to 100Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 100Base-LX/LH standards, the MC211GS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MT-211GS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on both transmitting and receiving data.



Categories: ,

Overview

The MT-211GS is a media converter designed to convert 100BASE-LX/LH fiber to100Base-T copper media or vice versa. Designed under IEEE802.3ab 100Base-T and IEEE802.3z 100Base-LX/LH standards, the MC211GS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MT-211GS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on both transmitting and receiving data.

Features

  • Works at 100Mbps in Full-Duplex mode for both TX port and FX port.
  • Supports auto MID/MID-X for TX port.
  •  Provides switch configuration of Force /Auto transfer mode for FX port.
  • Extends fiber distance up to 20km.
  • Easy-to-view LED indicators provide status to monitor network activity easily.
  • External power supply.
Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Basic Function Adopts WDM technology
Half/Full-Duplex transfer mode for FX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Link Fault Pass through and Far End Fault minimize the loss caused by link failure timely
Extends fiber distance up to 20km
Ports 1 100M SC port
1 100M RJ45 port (Auto MDI/MDIX)
WDM TX
RX		 1550nm
1310nm
Network Media 100BASE-T


1000BASE-T


1000BASE-FX		 UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)

UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 150m)

Single-mod Fiber
LED Indicators PWR, FDX/Col, Link/Act, SPD
